ST STM32F030K6T6

STM32F030K6T6
Mfg. Part Number
STM32F030K6T6
Manufacturer
Product Category
Embedded - Microcontrollers
Brief Description
IC MCU ARM 32F030K6T6 32K FLASH 32LQFP HOT SELLING NEW IN STOCK
Datesheet Download
Download
Availability of STM32F030K6T6

Available Quantity

38500 Pieces

Can ship today

Ships from: HONGKONG
Date Code: Newest Date Code 20+
Manufacturer lead time 20 weeks

Marketing Price
$ 1.56
Our Price
$ 1.20

QUANTITY



EIS Components is the stocking Distributor of STM32F030K6T6, we specialize in ST all series electronic components. STM32F030K6T6 can be shipped within 24 hours after order. If you have any demands for STM32F030K6T6, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
Our email: [email protected]
STM32F030K6T6 Order Process
Add Parts to RFQ form
Submit RFQ
We reply within 24 hours
You confirm order
Payment
Ship out your order
Specifications of STM32F030K6T6
Internal Part NumberEIS-STM32F030K6T6
Lead Free Status / RoHS StatusLead free / RoHS Compliant
Moisture Sensitivity Level (MSL)3 (168 Hours)
Production Status (Lifecycle)In Production
ConditionNew & Unused, Original Sealed
Product Training ModulesHealthcare and Wellness
STM32Cube
Design ResourcesDevelopment Tool Selector
Standard Package1500 Pieces per box package
Category Integrated Circuits (ICs)
FamilyEmbedded - Microcontrollers MCU IC
SeriesSTM32 F0
PackagingTray and BOX
Core ProcessorARM® Cortex®-M0
Core Size32-Bit
Speed48MHz
ConnectivityI²C, SPI, UART/USART
PeripheralsDMA, POR, PWM, WDT
Number of I/O26
Program Memory Size32KB (32K x 8)
Program Memory TypeFLASH
EEPROM Size-
RAM Size4K x 8
Voltage - Supply (Vcc/Vdd)2.4 V ~ 3.6 V
Data ConvertersA/D 12x12b
Oscillator TypeInternal
Operating Temperature-40°C ~ 85°C
Package / CaseLQFP-32
Supplier Device Package32-LQFP (7x7)
Weight0.003 KG
ApplicationEmail for details
Alternative Part (Replacement)STM32F030K6T6TR
Related LinksSTM32F, STM32F030K6T6 Datasheet, ST Distributor
Photos of STM32F030K6T6
STM32F030K6T6 STM32F030K6T6 STM32F030K6T6 STM32F030K6T6
STM32F030K6T6 Overview

The STM32F030x4/x6/x8/xC microcontrollers incorporate the high-performance Arm® Cortex®-M0 32-bit RISC core operating at a 48 MHz frequency, high-speed embedded memories (up to 256 Kbytes of Flash memory and up to 32 Kbytes of SRAM), and an extensive range of enhanced peripherals and I/Os. All devices offer standard communication interfaces (up to two I2Cs, up to two SPIs and up to six USARTs), one 12-bit ADC, seven general-purpose 16-bit timers and an advanced-control PWM timer.

The STM32F030x4/x6/x8/xC microcontrollers operate in the -40 to +85 °C temperature range from a 2.4 to 3.6V power supply. A comprehensive set of power-saving modes allows the design of low-power applications.
The STM32F030x4/x6/x8/xC microcontrollers include devices in four different packages ranging from 20 pins to 64 pins. Depending on the device chosen, different sets of peripherals are included. The description below provides an overview of the complete range of STM32F030x4/x6/x8/xC peripherals proposed.
These features make the STM32F030x4/x6/x8/xC microcontrollers suitable for a wide range of applications such as application control and user interfaces, handheld equipment, A/V receivers and digital TV, PC peripherals, gaming and GPS platforms, industrial applications, PLCs, inverters, printers, scanners, alarm systems, video intercoms, and HVACs.

Key Features

  • Core: Arm® 32-bit Cortex®-M0 CPU, frequency up to 48 MHz
  • Memories
    • 16 to 256 Kbytes of Flash memory
    • 4 to 32 Kbytes of SRAM with HW parity
  • CRC calculation unit
  • Reset and power management
    • Digital & I/Os supply: VDD = 2.4 V to 3.6 V
    • Analog supply: VDDA = VDD to 3.6 V
    • Power-on/Power down reset (POR/PDR)
    • Low power modes: Sleep, Stop, Standby
  • Clock management
    • 4 to 32 MHz crystal oscillator
    • 32 kHz oscillator for RTC with calibration
    • Internal 8 MHz RC with x6 PLL option
    • Internal 40 kHz RC oscillator
  • Up to 55 fast I/Os
    • All mappable on external interrupt vectors
    • Up to 55 I/Os with 5V tolerant capability
  • 5-channel DMA controller
  • One 12-bit, 1.0 μs ADC (up to 16 channels)
    • Conversion range: 0 to 3.6 V
    • Separate analog supply: 2.4 V to 3.6 V
  • Calendar RTC with alarm and periodic wakeup from Stop/Standby
  • 11 timers
    • One 16-bit advanced-control timer for six-channel PWM output
    • Up to seven 16-bit timers, with up to four IC/OC, OCN, usable for IR control decoding
    • Independent and system watchdog timers
    • SysTick timer
  • Communication interfaces
    • Up to two I2C interfaces
    • Up to six USARTs supporting master synchronous SPI and modem control; one with auto baud rate detection
    • Up to two SPIs (18 Mbit/s) with 4 to 16 programmable bit frames
  • Serial wire debug (SWD)
  • All packages ECOPACK®2
